Enhance Your Infrastructure with Low Grange Quarry's Freestanding Concrete Walling Solutions
At Low Grange Quarry Ltd, we specialize in manufacturing high-quality, prestressed, precast concrete wall panels designed for a multitude of applications. Our freestanding concrete walling solutions are engineered for durability, versatility, and ease of installation, making them ideal for various sectors, including agriculture, warehousing, storage, soil retention, and security.
Why Choose Our Freestanding Concrete Walling?
Robust Construction: Our panels are manufactured using 9.3mm diameter steel strands, tensioned during the casting process to enhance structural integrity.
Versatile Applications: Suitable for agricultural storage (livestock, grain, roots, silage), warehouses, general storage, soil retention, and security barriers.
Customisable Dimensions: Available in lengths up to 6 meters, depths ranging from 0.5 to 1.5 meters, and thicknesses of 100mm, 150mm, 180mm, and 225mm to meet specific project requirements.
Efficient Installation: Designed with tongue and groove fittings on the top and bottom edges, facilitating rapid assembly and a clean finish.
Complete Installation Kit: Each panel is supplied with galvanised plates, bolts, washers, and sealant. Lifting loops are available upon request to assist with handling and placement.
Quality Assurance: All panels are CE marked, ensuring compliance with European standards for safety and performance.
Technical Specifications:
Concrete Mix: 440 cement content with a water-cement ratio of 0.45, providing a 30mm coverage over the tensioned steel strands for enhanced durability.
Prestressing Process: Post-casting, the tensioned wires are cut, leaving them under stress within the panel, which contributes to the panel's strength and load-bearing capacity.
Dimensions:
- Length – Up to 6 metres
- Depth – 0.500 0.600, 1 metre, 1.2 metres, 1.5 metres
- Thicknesses 100 mm, 150 mm, 180 mm and 225mm
